Wireless DMX converter

Category: DMX Show controller Tag: DMX Show controller

Description
Reviews (0)

Description

The Wireless DMX converter is engineered for Air-DMX protocol fountains, combining durability and affordability in a compact design. It delivers a maximum frame rate of 50fps with full DMX 512 channel capability, ensuring smooth and high-quality performances. The unit features a fanless, ruggedized design with DIN-rail mounting and an energy-efficient CPU chipset, suitable for demanding environments. It operates across a broad temperature range and includes DMX 512/1990 ports. The intuitive LCD user interface simplifies setup and operation, making it a practical choice for efficient fountain control.

Features and Benefits

DMX show controller, designed for Air-DMX protocol fountain.
Durable, compact, low cost.
Maximum frame rate 50fps with full DMX 512 channels
DIN-rail mounting fanless ruggedized embedded systems with extra low power CPU chipset.
Made for the rugged environment, this compact unit supports wide temperature range and features DMX 512/1990 ports.
Easy set-up with friendly LCD user interface

Technical information

	WL-DMX-1
Dimensions (LxWxH)	37 x 90 x 58 mm
Power supply	18..30V DC/ 20W
Feature	● Wireless DMX (Air-DMX) protocol ● Max. Distance: 150 meter without obstruction, depends on real condition(For safe usage: Max Distance 30 meter)● Frequency: 2.4 GHz RF-band: 2402-2480MHz. Compliance: EN IEC 62311:2020, EN 50665:2017 (Report No. R2106A0561-M1V1), EN 55032:2015+A11:2020, EN 55035:2017+A11:2020 (Report No. R2106A0561-E1V1)● 16 selectable group: choose from LCD screen
DMX channels	Full range 512 channels. Standard DMX512-1990
