DMX switch SSR-16-IP68
DMX-SSR-16
16 Channels Solid State Relay output
This DMX-SSR-16 to drive electronic control components in a multimedia show environment. The Decoder has 16 outputs (type NPN). It is the perfect tool to directly control Solenoid valve, DC light bulb into a DMX512 network.
The DMX bus should be terminated with a 120 Ohm resistor (not included).
Description
Features and Benefits
- 16x SSR (Solid state relay or Non-contact relay) @ 24VDC – 5A
- DMX address can be set via our software device manager
Technical information
| DMX switch DMX SSR-16-IP68 | |
| Dimensions (LxWxH) | 190 x 90 x 58 mm |
| Power supply | 12..30V DC/ Max.30A |
| Outputs | 16x SSR outputs @ 12..30VDC – 5A |
| DMX channels | 16 channels – 16 SSR outputs: ● DMX value: 0à127: OFF ● DMX value: 128à255: ON |
